A non-return valve can be used to help prevent waste backflow on electric toilets. |
Model | Description | Price |
---|---|---|
58109-1000 | 1-1/2" (38mm) Outlet Non-Return Joker Valve | 44.56 € |
A check valve gives quicker and easier flushing response on many manual and
37010 Series Electric Toilet installations. |
Fitting | Size | Weight |
3/4" (19mm) ID hose | 10.8cm x 5.5cm x 5cm | 0.1Kg |
Model | Description | Price |
---|---|---|
29295-1011 | Inlet Non-Return Valve | 40.80 € |
Robust Y-Valve for use in toilet applications. Allows waste to be pumped overboard or into a holding tank. |
Fitting | Size | Weight |
two 1-1/2" (38mm) ports and 1" (25mm) inlet port | 20cm x 19cm x 12cm | 0.9Kg |
An essential safety component on all inlet and discharge plumbing of toilets installed below the static or heeled waterline. |
Fitting | Size | Weight |
3/4" (19mm), 1" (25mm) and 1-1/2" (38mm) ID hose | 3/4"=7.5x9.5x2.5 1"=12.5x19x4.5 1 1/2"=12.5x18.5x5 |
3/4" Model:(0.04kg) 1" Model: (0.13kg) 1-1/2" Model: (0.2kg) |
Robust diaphragm pump passes solids and is particularly effective in emptying holding tanks. |
Fitting | Size | Weight |
1-1/2" (38mm) ID hose | 27.7cm x 15.5cm x 11.1cm | 2.7Kg |
Model | Description | Price |
---|---|---|
50890-1000 | 12V DC, fuse 10 amp | 472.43 € |
50890-1100 | 24V DC, fuse 5 amp | 467.45 € |
SK890 | Service Kit | 42.77 € |
The latest version of the Macerator Pump now has a fully sealed motor and a new, more powerful chopper blade. |
Fitting | Size | Weight |
1-1/2" (38mm) hose barb plus 1-1/2" (38mm) NPT Inlet port, Discharge Port: 1" (25mm) hose barb |
29cm x 12cm x 9cm | 2.3Kg |
The Pumpgard protects manual or electric toilets from pump malfunctions caused by debris. |
Fitting | Size |
3/4" (19mm) ID hose | 12cm x 7cm x 6cm |
Model | Description | Price |
---|---|---|
46400-0000 | Toilet Pumpgard | 37.75 € |
18753-0040 | Replacement 40# Mesh Filter | 23.03 € |
Where 37010 Series Electric Toilets are installed below the waterline,
we recommend installing a loop on the inlet plumbing rising at least 8" (20cm) above the highest (static or heeled) waterline level,
and installing a vented loop fitting at the top of the loop to stop water siphon over the loop and flooding the vessel. |
